Page 54
6. External Dimensions
48
6.2 Long Stroke Type
Single Slider Type
6.2.1 SA4L
Detail D
4
3H7
+0.010 0
40
25
15
13
9
14
M.E.
S.E.
19.5
20
5
2-φ2H7 depth 2
4-M2 depth 3
12
17
± 0.02
12
Stroke
30
28.5
L (Stroke+78)
Home
M.E.
Oblong Hole, depth 4 (D)
1
A × 30
P
C
30
15
13.5
φ 3H7 depth 4
B-M3 depth 5
14
26
1
D
Ma Moment datum point for offset
(Reamer pitch tolerance ±0.02)
(0.6)
(30)
(0.6)
(1)
(300)
(1)
(21.3)
Secure at least 100
M.E.
S.E. : Stroke End
: Mechanical end
(through)
Cable joint connector
Stroke
30
60
90
120
150
180
L
108
138
168
198
228
258
A
3
4
5
6
7
8
B
4
5
6
7
8
9
C
60
90
120
150
180
210
Weight [kg]
0.21
0.25
0.29
0.32
0.36
0.4
