5. Maintenance Inspection
45
5.6.2 Long Stroke Type SA4L, SA5L, SA6L
SM4L, SM5L, SM6L
1) Remove the old stainless steel sheet.
Prepare a piece of plain paper (with thickness of
approximately 0.1mm) and cut it in a size with the
width in the same as stainless steel sheet (SA4: 8mm
and SA5/6: 11mm) and length longer than the slider
cover.
2) Put the paper prepared in 1) through under the slider
cover as shown in the picture.
3) Put a new stainless steel sheet through along the
paper.
4) Remove the paper, and tighten the Phillips-head
screws with using a precision Phillips screwdriver to
attach the stainless steel sheet.
