2. Installation
29
[2] Long Stroke Type
Tapped hole for base attachment
Base seating surface
Reamed hole for positioning
Slotted hole for positioning
Recommended screw torque
Type
Tapped
holes
diameter
Effective
tapped
depth
Seating surface :
Copper
Seating surface :
Aluminum
Reamed
holes
diameter
Effective
reamed
depth
Single Slider Type SA4L
Double Slider Type SM4L
Single Slider Type SA5L
Double Slider Type SM5L
M3
154N㨯cm
(15.8kgf㨯cm)
83N㨯cm
(8.47kgf㨯cm)
I 3H7
Single Slider Type SA6L
Double Slider Type SM6L
M4
5mm
359N㨯cm
(36.7kgf㨯cm)
176N㨯cm
(18kgf㨯cm)
I 4H7
4mm
Caution: Select a screw length that suits to the effective thread depth. In case that an
insufficient screw is used, it may cause damage on the tapped holes or insufficiency
in the strength.
