5. Maintenance Inspection
44
5.6 Replacement of the stainless steel sheet
5.6.1 Slim Type SA1L, SA2L, SA3L
1) Remove the Phillips-head screws with using a
precision Phillips screwdriver No. 0, and detach the
oil stainless steel sheet.
Prepare a piece of plain paper (with thickness of
approximately 0.1mm) and cut it in a size with the
width in the same as stainless steel sheet (SA1L:
8mm and SA2L/3L: 11mm) and length longer than
the slider cover.
2) Put the paper prepared in 1) through under the slider
cover as shown in the picture.
3) Put a new stainless steel sheet through along the
paper.
4) Remove the paper, and tighten the Phillips-head
screws with using a precision Phillips screwdriver to
attach the stainless steel sheet.
