11
Names of the Parts
In this manual, the right and left sides of the actuator are expressed in the way it is placed horizontally
as shown in the figure below, and is looked at from the motor side.
Ɣ Slim Type
SA1L, SA2L, SA3L
Cable joint connector
Side cover
Slider
Cable
Base
Encoder cover
Stainless steel sheet
Front Rear
(Home position side) (Opposite home position side)
Ɣ Long Stroke Type SA4L, SA5L, SA6L
SM4L, SM5L, SM6L
Front Rear
Side cover
End cover End cover Stainless steel sheet
Slider
Cable
Base
Cable joint connector
(Home position side) (Opposite home position side)
