4. Operational Conditions
38
4.1.2 Long Stroke Type
SA4L, SA5L, SA6L
SM4L, SM5L, SM6L
The graph below shows the upper limit of transportable weight and acceleration available for
continuous operation.
Type
SA4L, SM4L
SA5L, SM5L
SA6L, SM6L
Acceleration
[G]
Continuous operation
available
Continuous operation
available
Continuous operation
available
0.3
0.8
1.6
3.2
0.5
0.5
1.0
2.0
1.0
0.25
0.5
1.0
1.5
0.18
0.35
0.65
2.0
0.14
0.25
0.5
4.0
3.0
2.0
1.0
0
0
0.5
1
1.5
2
0.8
0.6
0.4
0.2
0
0
0.5
1
1.5
2
1.0
2.0
1.5
1.0
0.5
0
0
0.5
1
1.5
2
SA4L, SM4L Transportable Weight (horizontal) and Acceleration
SA6L, SM6L Transportable Weight (horizontal) and Acceleration
SA5L, SM5L Transportable Weight (horizontal) and Acceleration
Acceleration [G]
Weight [kg]
Acceleration [G]
Weight [kg]
Acceleration [G]
Weight [kg]
