Section 1: General Information
01/13 8 51297 Rev. 1
1.2. Main Product Features, Continued
•
The PC2255 software utility program can also upload and modify the instruments
set-up, configuration, and calibration.
– Saved information can be downloaded from a computer to the FB2255 Series
in the event of a catastrophic failure.
•
The instrument provides two (2) serial communication ports to provide
communication to various types of peripheral devices for RS232, RS422, RS485,
and 20mA data outputs.
•
Optional accessories include a 4-20 mA Analog Output, a Bluetooth® serial
adapter, and three different fieldbus devices; Profibus®, DeviceNet™, and
Ethernet/IP.
1.3. Specifications
1.3.1. INSTRUMENT APPROVALS
•
CC 09-023
•
MC AM-5720
•
ETL ETL Listed
•
Conforms to ANSI/UL STD 60950-1
•
Certified to CAN/CSA C22.2 STD NO. 60950-1-03
1.3.2. BASIC SPECIFICATIONS
•
ENCLOSURE
ABS, Black NEMA 1, Stainless Steel NEMA 4X Desk and Wall
Mount
•
DISPLAY 6-digits, One inch (1”) LCD, Green Backlight
•
FRONT PANEL KEYS On/Off, Units, Zero, B/G, Net, Tare and Print
•
UNITS lbs., oz, kg, g and lbs/oz, or custom
•
GRADUATION SIZE 0.0001 to 50
•
AD CONVERSION 66 per second
•
LOAD CELL EXCITATION 5 Volts DC
•
SENSITIVITY 1µv/d (microvolt/division)
•
LOAD CELLS Eight (8) 350 ohm or Sixteen (16) 1000 ohm
•
DISPLAYED DIVISIONS 10,000d Commercial and 100,000d Non-Commercial
•
CAPACITIES Programmable to 999999
