01/13 7 51297 Rev. 1
Section 1: General Information
1.1. Model Descriptions
The FB2255 is a general purpose weighing instrument that can be used with a wide
variety of platforms and load receivers, and is available in eight (8) different
configurations.
MODEL PART NO.
•
FB2255-1 Series ABS, AC Power 32351
•
FB2255 Series ABS, AC/Battery Power with Bracket 32449
•
FB2255-2 Series SS, AC Power 32352
•
FB2255 Series SS, AC/Battery Power with Bracket 32450
•
FB2255 Series SS, AC Power, No Bracket 32451
•
FB2255 Series SS, AC/Battery Power, No Bracket 32452
•
FB2255 Series SS, AC Power, No Bracket, IP69K 32453
•
FB2255-K Series SS, AC Power, IP69K 32352
1.2. Main Product Features
Major features of the Instrument include the following.
•
Push-button programming and calibration.
•
Program data is stored in battery supported ram and backed up in flash memory.
– The battery should be replaced every twelve (12) months.
•
The FB2255 series instrument features a large one inch (1”) green backlit LCD
weight display, which can be tilted up or down to accommodate different lighting
conditions.
– Microprocessor controlled design allows the instrument to be rapidly
programmed at installation to meet the specific requirements of the
application.
•
The obtainable accuracy meets Handbook 44 requirements, and the instrument is
approved for commercial application up to 10,000 divisions.
– A maximum of 100,000 displayed divisions can be programmed for non-
commercial applications.
•
A computer utility software program PC2255 is available, downloaded from
Fairbanks Intranet for programming using the computer, and is required for
certain features such as custom ticket formatting.
