Section 6: PC2255 Utility Software

01/13

61

51297 Rev. 1

6.11. Custom Output – Tokens, Continued

4. Make a selection, such as

, for

example.

– This inserts a Start of Header

character… otherwise known as a
CTRL/A, or 0x01 HEX.

5. When entering a character not listed, select

ENTRY

.

6. Select

ENTRY

to insert a character using

the keyboard, such as an A or a 1.

6.12. Custom Output – Weights

A variety of settings are available for the
Weight Digits window. These choices include
the following.

Weight Digits

Leading Zeros

Justification

Decimal Point

Fixes Decimal

Places

Include Polarity (checkbox)

Positive Token

Negative Token
