Appendix 1: Data Output Formats

01/13

72

51297 Rev. 1

I. UPS

Serial Data Output Format

for UPS Worldship Software.

The instrument will transmit the following string of data.

Character Number

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18

String 1

Gross Weight:

X X X X . X X SP l/k b/g SP G/g R/r SP SP CR LF EOT

NOTES:

Characters denoted by

“X”

are characters 0-9.

– Leading zeroes are replaced with spaces (SP).

Character 5 is a decimal point (HEX 2E).

Lower case

“I”

and

“b”

for Avoirdupois Units, or

“k”

and

“g”

for Metrics

Units.

The first weight character will be a

minus

(

), HEX 2D, If weight is negative.

Characters separated with a

“/”

denoted one of the characters will be

transmitted.

– Lower case

gr

in characters 12 and13 indicates scale motion.

– Upper case indicates stable weight.

EOT

,

HEX 04 is transmitted in “HiCAP” condition.

Transmission will occur when a

CR

(Hex 0D) carriage return is received.
