E. condec continuous output, F. demand output – Fairbanks FB2255 Series Instrument PC2255 PC Software Utility Program User Manual
Page 69
Appendix 1: Data Output Formats
01/13
69
51297 Rev. 1
E. Condec Continuous Output
P = Polarity
space = positive weight
- = negative weight
W = Displayed weight
U = Units
L = pounds
K = kilograms
G = Gross; N = Net
M = Motion
Leading zeros are suppressed
F. Demand Output
Activated by the receipt of a
Gross Weight – No Motion – decimal points included
Gross Weight – Motion – decimal points included
Net Weight – No Motion – decimal points included
