Section 6: Fieldbus/Bluetooth
01/13 47 51297 Rev. 1
5.3. Bluetooth ® Technology Device, Continued
Set the 4-position Dip Switch on each device as shown below.
Follow these steps to installing the Bluetooth
®
Devices.
5. Turn on both Bluetooth
®
Devices with the
SLIDE SWITCH on their sides.
6. Press the RESET BUTTON on each one.
7. Press the PAIRING BUTTON of Device #1
for two (2) seconds
– The Standby LED turns OFF .
– The Connect LED blinks three (3) times
every two (2) seconds.
– Keep the power ON .
8. Press the PAIRING BUTTON of Device #2
for two (2) seconds.
– The Standby LED turns OFF.
– The Connect LED blinks three (3) times every two (2) seconds.
9. Press the Pairing Button again for two (2) seconds until the Connect LED blinks
every half (½) second.
•
Wait for Devices #1 and #2 to connect to
each other.
– The Connect LEDs of both will be
solid green.
– This connection process takes about
ten (10) seconds.
– If any other Bluetooth
®
devices are
nearby, it may take longer.
1,2,3 ON
4 OFF
Baud Rate 9600
Data Bits 8
Parity None
Stop Bit 1
