Section 6: PC2255 Utility Software
6.1. Introduction
•
The PC2255 utility software program can be used to set up and configure the
FB2255.
•
It is required in order to program certain features, such as custom units and
custom ticket vector programming.
•
The FB2255 uses
Port 2
to communicate to the computer.
6.2. Communication Settings
1. Access the COM Port Settings of the computer by
pressing
F2
.
The Standard Defaults are noted in the chart to
the right.
2. Set
VERSION
setting to match the FB2255.
– It displays at the warm-up screen of the
Instrument.
3. Set the FB2255 Port 2 to the same settings,
and then exit from program mode.
Baud Rate
9600
Data Bits
8
Parity
None
Stop Bit
1
Mode
Continuous
USING THIS PC2255 UTILITY PROGRAM CAN ALTER
PROPER CALIBRATION AND USER FUNCTIONS.
OWNER ASSUMES ALL RISKS WHILE USING THIS PROGRAM!
THE CUSTOMER WILL BE RESPONSIBLE FOR ALL
SERVICE DEPARTMENT COSTS TO RESTORE THE
INSTRUMENT TO ITS PROPER OPERATIONS.
C
A
U
T
I
O
N
