Section 6: PC2255 Utility Software

01/13

56

51297 Rev. 1

6.7. Fieldbus / 4-20 mA, Continued

OUTPUT

Data from the FB2255 comprises of three (3) 32-bit words.

Gross Weight

Tare Weight

A 32bit Status Word

Gross and Tare weights can be selected as either a 32-bit Integer or a 32-bit

Floating Point Word.

The Most significant Byte indicates the Weigh Mode

"G"

for Gross, and

"N"

for Net.

The Next Order Byte indicates

"O"

Overcapacity,

"M"

Motion of the last

command received. (See INPUT Commands)

The next order byte indicates the weight units.

"l"

pounds

"k"

kilograms

"o"

ounces

"g"

grams.

The Least Significant Byte indicates the number of decimal places, if the weight
output is selected to be a 32-bit Integer word.

– If a Floating point word is selected, this byte will be

“0”.

INPUT

Single Byte Commands can be sent from the network.

– Although the input is read as a 32-bit word, only the Least Significant Byte is

used in this process.

– When the command is sent and recognized, it is entered into the 32 -bit status

byte in the Least Significant Command Byte location.

– New commands can be transmitted after transmitting a

NULL

command.
