C. cardinal 738 continuous scoreboard output, D. weightronics wi-120 continuous output – Fairbanks FB2255 Series Instrument PC2255 PC Software Utility Program User Manual
Page 68
Appendix 1: Data Output Formats
01/13
68
51297 Rev. 1
C. Cardinal 738 Continuous Scoreboard Output
W = Displayed weight
P = Polarity
+ = Positive weight
- = Negative weight
U = Units
lb = pounds
kg = kilograms
m = Motion or o = Overload
g = Gross; n = Net
SP = Space
Leading zeros are not suppressed
D. Weightronics WI-120 Continuous Output
G = Gross; N = Net
P = Polarity
+ = positive weight
- = negative weight
U = Units
lb = pounds
kg = kilograms
SP = Space
Leading zeros are not suppressed
