Front panel key functions, Zero – Fairbanks FB2255 Series Instrument PC2255 PC Software Utility Program User Manual
Page 13

01/13
13
51297 Rev. 1
Section 2: User Operations
2.1. Front Panel Key Functions
ON/OFF
Turns the Instrument on or off.
UNITS
Switches between pre-programmed selectable weight units.
ZERO
Sets the display to zero, programmable: 2% or 100% of capacity.
B/G – NET
Toggles between Gross and Net weights
•
This apples only if a Tare Value has been entered greater than ZERO.
TARE
Automatically tares off displayed weight when key is pressed.
Simple RS232 output when key is pressed.
0-9
Used for Programming and inputting manual tares.
MENU
Gains access to the sub-menus in the Configuration Mode.
ARROW
KEYS
Used for scrolling through the menu selections.
Depending on programmed selection, Tare Weight amount will do one of the
following.
•
Be retained for reuse until changed, or if power is removed.
OR…
•
Automatically clear when
Gross Weight returns to
ZERO
.
