Okidata 186 t form printer, continued – Fairbanks FB2255 Series Instrument PC2255 PC Software Utility Program User Manual
Page 28
Section 4: Input / Output
01/13
28
51297 Rev. 1
4.2. Okidata 186 T Form Printer, Continued
GROUP
ITEM
SET
Parallel I/F
I-Prime
Buffer Print
Parallel I/F
Pin 18
+5v
Parallel I/F
Bi-Direction
Enable
Serial PCB Assy Switch Settings: (SW1) (** indicates typical Fairbanks setting)
Parity Type
Switch 1 (SW1)
** Odd parity
ON
Even parity
OFF
Parity
Switch 2 (SW1)
** No parity
ON
With parity
OFF
Data Bits
Switch 3 (SW1)
** 8 Bits
ON
7 Bits
OFF
Protocol
Switch 4 (SW1)
Ready/Busy
ON
** X-ON, X-OFF
OFF
Test Select
Switch 5 (SW1)
** Circuit
ON
Monitor
OFF
Mode Select
Switch 6 (SW1)
** Print mode
ON
Test mode
OFF
Busy Line Selection
Switch 7, 8 (SW1)
SSD- Pin 11
OFF, ON
SSD+ Pin 11
OFF, OFF
** DTR- Pin 20
ON, ON
RTS- Pin 4
ON, OFF
(SW2) (** indicates typical Fairbanks setting)
