Appendix 1: Data Output Formats

01/13

74

51297 Rev. 1

J. P Ship, Continued

3.

UU

=

A two character weight identifier. If the scale is configured to

weigh kilograms, a "KG" (uppercase letters) will be returned, if

configured for pounds, "LB" (uppercase letters) will be returned.

4. The decimal point is returned by the scale as part of the ASCII string.

5. Interpretation of scale status digits

The high order nibble of each status byte has a value of 3 (0011 B). The low order
nibble of the first and second bytes are defined as follows:


1st Byte:

Bit 0 - High = scale is in motion

Low = scale is stable

Bit 1 - High = scale at zero

Low = scale not at zero

Bit 2 - Low = not used

Bit 3 - Low = not used



2nd Byte:

Bit 0 - High = scale is below zero

Low = scale is not below zero

Bit 1 - High = scale is over capacity

Low = scale is not over capacity

Bit 2 - High = scale ROM program failure

Low = scale ROM okay

Bit 3 - High = faulty calibration data*

Low = scale calibration okay


*This is the result of an incorrect checksum


An example of the scale response to an "S" command would be:

S20


The following status conditions are in effect for this response:

•scale at zero

•scale is not below zero

•scale is not over capacity

•scale ROM okay

•scale calibration okay
