Section 4: Input / Output

01/13

35

51297 Rev. 1

4.6.1.

PROGRAMMING THE 4-20MA ANALOG OUTPUT MODE

Access to this features is conditional, and depends upon whether it is enabled in the
FB2255 Internal Programming.

1. Press and hold the

UNITS

key for three (3) seconds

NOTE

: If 4-20mA Analog Output has been installed and programmed, setting 4-20

to

NO

in the APPS Menu will prevent access to it from the front panel while the

analog output continues to operate.

2. Select

GROSS

or

NET

.

– The 4-20 mA Analog Output will continue to track the selection regardless of

the currently selected Weigh Mode.

3. Press

MENU

.

4. Press the

right arrow

key to toggle the available settings.

5. Press

ENTER

to select an option.

Available selections include the following.

Gross

Net

4.6.2.

PROGRAMMING THE 4mA WEIGHT VALUE

4.20 Lo displays, followed by the current setting.

1. Key in the correct Weight Value with the

0-9

keys.

2. Press

ENTER.

This weight entry results in a

4mA Output

.

4.6.3.

PROGRAMMING THE 20mA WEIGHT VALUE

4.20 Hi displays, followed by the current setting.

3. Key in the correct Weight Value with the

0-9

keys.

4. Press

ENTER.

This weight entry results in a

20mA Output

.
