SECTION 1: GENERAL INFORMATION
1.1. INTRODUCTION
The Omega Counting Scale is designed for both light capacity weighing
applications and with a remote scale attached, applications up to 10,000 pounds.
It is also designed for quick accurate counting of large quantities of like objects.
1.2.DESCRIPTION
The self-contained, weighing platform and instrument, Omega Counting Scale is
designed in a rugged ABS plastic enclosure with a stainless steel weighing
platform, perfect for almost any counting scale application. The extremely large
9.64” x 13.97” weighing platform can easily accommodate most parts counting
needs. The Omega Counting Scale comes with a lead-acid rechargeable battery,
remote scale connection, and dual RS232C serial ports. Serial port 2 is
dedicated to barcode readers. Capacities range from 6 to 100 pounds.
1.3. TECHNICAL SPECIFICATIONS
1.3.1. BASIC SPECIFICATION
Digital Display
LCD, height 0.6 in (14.5 mm)
6/7/7(Weight / Piece Weight / Total Pieces)
Platter Size (W x H) 9.64 x 13.97 in (245 x 355 mm)
Dimensions (W x L x H) 15.24 x 14.37 x 4.61 in (387 x 365 x 117 mm)
Net Weight(kg) 8.16 lbs (3.7 kg)
Operating
Temperature
32˚F to +104˚F (0℃ to +40℃)
Relative
Humidity
Less than 85%
Power
9V / 500mA, AC adapter;
Built in 6V Rechargeable Battery
•15-20 hours continuous
•7-10 hours continuous with an external platform
•14-16 hours recharge time
Interface RS-232C, Serial 1 and Serial 2
