Section 7: Serial Input / Output
7.1. INTRODUCTION
The Omega Series Scale has two RS232C ports, Serial 1 and Serial 2. Serial 1 is
dedicated for use with printers and Serial 2 is strictly for scanner/readers to input data
into the Omega Scale. Serial 1 is located on the rear panel and Serial 2 is located on
the right side panel.
7.2. 2844 PRINTER SETUP AND PROGRAMMING
The Omega Series scale in conjunction with the 2844 label printer provide templates
as a solution to our customers’ label printing needs and label printing requirements.
Please consult with your authorized Fairbanks representative for setup and
programming.
7.3. SETTINGS FOR THE OMEGA COUNTING SCALE
7.3.1. CABLE REQUIREMENT
Use cable part number 20483 M-F Null modem cable for the printer interface
cable.
7.3.2. OMEGA SERIES LABEL SELECTION PROGRAMMING
A. OMEGASETTINGS FOR ALL PRINTERS
PRT
Ser.1 = PrESS
bAUd = 9600
PArit = 8-n-1
