Notes:
1. SYStem must be cycled prior to setting [INDICATION SELECT] functions.
2. A minimum of (7) fastening cycles must be completed before the statistics (6
/ CPk) are calculated and displayed.
3. A maximum of 500 cycles of data are stored for each spindle, however the number of
cycles stored varies depending on the number of spindles connected.
1-6 Spindles = 500 cycles per spindle
6-12 Spindles = 250 cycles per spindle
12-18 Spindles = 166 cycles per spindle
18-24 SPINdles = 125 cycles per spindle
4. AFter the maximum cycles are stored, the next cycle will overwrite the data for the first
cycle.
7.7.4 sCREEN SCROLLING AND PRINTOUT FUNCTIons
4-1. THe STORED DATA screen is capable of displaying up to (24) items with up to (500)
sets of stored data for each spindle. DUe to the screen size, only (15) items and (5)
cycles of data may be displayed at once. Therefore, scrolling is necessary.
4-2. Using the
[←] [→]
keys move the cursor to [UP], [DOWN], [LEFT] or [RIGHT] and
depress the
[↵]
key to scroll.
4-3.
The [UP] [DOWN] position will scroll (15) items of the fastening data for each spindle.
The [LEFT] [RIGHT] position will scroll the stored data from 001 to 500.
4-4. TO print the fastening data displayed on the screen, move the cursor on the menu
bar to [PRINT] and depress the
[↵]
key.
