LENGTH Permanent elongation, calculated automatically if
angle is entered
ANGLE Rotation into yield, calculated automatically if length is
entered
YIELD RATE Final target TORQUE RAte for a period equal to the preset
angle
CONSTANT
Compensation factor for permanent elongation
(default = 1.00)
NOTE: CROSsover points can be set in either torque or angle, but not both.
CROSSOVER AREA Threshold 2 Torque plus area angle = Area Yield Method
ANGLE calculation start point
CROSSOVER AREA
Area Yield Method calculation start point
TORQUE
1ST TORQUE Seat torque (1st TORQUe), end of 1st TORQUE RAte
measurement, start of 2nd TORQUE RAte measurement
1ST ANGLE
SEat angle (1st Angle), end of 1st TORQUE RATE
measurement, start of 2nd TORQUE RATE measurement
CROSSOVER RATE 2
End of 2nd TORQUE RATe measurement, start of
3rd
ANGLE
TORQUE RAte measurement, start of INTEGRATED Yield
Method calculation
CROSSOVER RATE2
end of 2nd TORQUE RATe measurement, start of 3rd
TORQUE TORQUE RATe measurement, start of INTEGRATED Yield
Method calculation
SPEED CHANGE shiftpoint from 1st STep to torque speed
TORQUE
THRESHOLD 1 TORQUE
sTart of 1st TORQUE RATE measurement
THRESHOLD 2 TORQUE Start of FINAL Angle measurement
2ND ANGLE
ANgle for 2nd Step in multi-step fastening
3RD ANGLE
ANgle for 3rd Step in multi-step fastening
2ND TORQUE
TOrque for 2nd Step in multi-step fastening
3RD TORQUE
torque for 3rd Step in multi-step fastening
HIGH TORQUE
High torque limit
LOW TORQUE
LOw torque limit
HIGH ANGLE
High final angle limit
LOW ANGLE
LOw final angle limit
1ST TORQUE RATE HIGH
HIgh limit for 1st TORQUE RATE
