7.3.4 VOCABULARY LIST [FASTENING DATA]
PEAK TORQUE HIGHest torque value measured during fastening
OFFSET TORQUE
PREvailing torque value measured during OFFSET CHEck
(CHeck must be enabled via sequence or external input)
FINAL TORQUE FINal torque value measured upon completion of fastening
FINAL ANGLE
FINal angle value measured upon completion of fastening
(measured from snug torque)
ELONGATION ANGLE ANGle value measured from the detected yield point to
completion of fastening
ELONGATION LENGTH CALculated amount of permanent elongation of the fastener
1ST TORQUE RATE
HIGHest 1st TORQUE RATe value when using the
Integrated
HIGH
TORQUE RATe calculation method. Average 1st TORQUE
RATe
value when using the POINT-TO-POint calculation method
1ST TORQUE RATE LOwest 1st TORQUE RATe value when using the Integrated
LOW TORQUE RAte calculation method. Not utilized when using
the POINT-TO-POint calculation method
2ND TORQUE RATE
Highest 2nd TORQUE Rate value when using the Integrated
HIGH TORQUE Rate calculation method. Average 2nd TORQUE
RAte value when using the POINT-TO-POInt calculation
method
2ND TORQUE RATE LOWEST 2nd TORQUE RATE value when using the
Integrated
LOW
TORQUE Rate calculation method. NOT utilized when using
the POINT-TO-POint calculation method
3RD TORQUE RATE Highest 3rd TORQUE RAte value when using the Integrated
HIGH TORQUE RATE calculation method. Average 3rd TORQUE
RATE
value when using the POINT-TO-POint calculation method
3RD TORQUE RATE LOWest 3rd TORQUE RATE value when using the
Integrated
LOW
TORQUE RATE calculation method. NOT utilized when
using
the POINT-TO-POInt calculation method
1ST RATE INC TORQUE
CHAnge in torque as measured from THRESHold1 torque
until 1st Torque/Angle
1ST RATE INC ANGLE
CHange in angle as measured from Threshold1 torque until
1st Torque/Angle
2ND RATE INC TORQUE
CHAnge in torque as measured from 1st Torque/Angle until
CROSSOVER RATe2 Torque/Angle
2ND RATE INC ANGLE
cHANge in angle as measured from 1st TOrque/Angle until
CROSSOVER RATE2 Torque/Angle
