(normally CCW) rotation.
7.2 LIMIT PARAMETER: The function of this screen is to view the preset limit
parameters of all nutrunners connected to the System.
data that has been preset on the "Set Parameter" screen is
displayed in a table format on this page.
7.3 FASTENING DATA: Displays the fastening results of the previous operation.
7.4 FASTENING Displays the torque signature (torque/angle or torque/time)
TORQUE CURVE: of the previous operation for up to five (5) spindles.
7.5 SET SEQUENCE: The fastening sequence is programmed using this screen.
UP to eight (8) sequences may be set.
7.6 SEQUENCE Displays the fastening sequence steps in progress while
INDICATION: fastening is being performed.
7.7 STORED DATA: Displays previous fastening results.
7.8 STORED DATA THe function of this screen is to view the total number of
COUNT: accept, reject, abnormal, and bypassed fastening cycles.
7.9 SYSTEM
Configuration of the System clock and communication for
CONFIGURATION: the Centronics, RS422 (option), and RS232C ports are
preset on these screens.
7.10 MACHINE Configuration of the System is preset on this screen.
CONFIGURATION:
7.11 PREAMP Displays the information that has been programmed into the
EEPROM DATA: tool preamp EEPROM.
7.12 TORQUE Adjustment of the calibration value of the FEC INC. torque
CALIBRATION:transducer is performed with this screen.
7.13 DATA FILE UTILITY: Setup of this screen determines the type and amount of
fastening data to be saved, as well as where (HDD or FDD)
the data will be saved.
7.14 PRESET FILE THE function of this screen is to load the System / machine
UTILITY: configuration, and the sequence and fastening parameter
presets.
7.15 FILE UTILITY: THE function of this screen is to perform file maintenance on
installed hard (HDD) disk and floppy (FDD) disk drives.
Chapter 7: System Operation
Page 7-4
