)(& ,QF

4-2d.

SELect YES or NO using the

[←] [→]

keys, then depress the

[↵]

key.

Refer to the "VOCABULARY LIST" sections 7.1.6 through 7.1.10 for details of
presetting for each fastening method, and to Chapter 6 for fastening instructions.

NOTES:

1. IF incorrect numerical data is entered, the System will display "INPUT ERROR".

2. "FReerun Time" and "Initial Time" may be set in either seconds or revolutions.

3. OFfset Check is only performed when either an input signal is present, or the

sequence program OFFSET CHeck (OF) function is enabled (set to "O").

4. The actual duration of high speed rundown time is equal to "Freerun" minus "Initial" time.

5. "1st time" minus "Freerun time" equals "Slowdown time"

6. When Speed change or 1st Torque is sensed, the System switches to Torque Speed.

Chapter 7: System Operation

Page 7-14
