S t a t i c s S y s t e m E q u i p m e n t
®
2 012-12876B
Important
When moving or removing any of
the magnetically mounted compo-
nents from the board, handle the
component by the magnetic base
rather than by the component itself.
This will reduce the strain on the
component.
A second board (available sepa-
rately) can be attached to the first
board with the three included con-
nector screws. To join the boards,
remove the connector screws from
the threaded holes on the side of
the first board. Put the edge of the
second board next to the first
board. Align the holes and join the
two boards with the connector
screws
.
No
No
Yes
Yes
Moving Components on the Board
Rear view of Statics Boards
Connector
screws
Use the Connector
screws to join two
Statics Boards together.
