Installation and Maintenance Manual
69
D0119, Rev. F
Pump Pack: Part Names and Part Numbers
SlideDriver 10, 40, 50VF2, 50VF3 (222 SS, E, X2, X3)
Part Name Part Number SlideDriver Models (current)
Breather Cap MX000686 all
Contactor, Mercury MX001098 all DC
Coupler, Motor, 5/8” Shaft MX001650 all
Gauge, Pressure, 2000 PSI, Kit MX001106 all
Inherent Sensor Kit MX000091 all
Manifold, Braking Kit, SlideDriver MX000137 all except 10 (SS, DS, CF)
Motor Starting Kit MX001308 all AC 60Hz 1Ø
Motor, Electric, 24VDC, 2.0 HP MX001647 10 UPS, 40 UPS, (DS, DE) 24VDC
Motor, Electric, 60Hz, 1.0 HP, 1Ø, 3450 RPM MX001635 10, 40 (SS, E) 115/208/230VAC 60Hz 1Ø
Motor, Electric, 60Hz, 1.0 HP, 3Ø, 3450 RPM MX001636 10, 40 (SS, E) 208/230/460VAC 60Hz 3Ø
Motor, Electric, 60Hz, 1.0 HP, 3Ø, 3450 RPM, 575VAC MX001667 10, 40 (SS, E) 575VAC
Motor, Electric, 60Hz, 2.0 HP, 3Ø, 3450 RPM MX001638 50VF (X2/X3)
Pump Pack, SlideDriver 10 MX000092 10, 10 UPS (SS, DS)
Pump Pack, SlideDriver 40 MX000093 40, 40 UPS (E, DE)
Pump Pack, SlideDriver VF2/VF3, 50/60Hz MX000620 50VF (X2/X3)
Quick Disconnect, Plug, 1/8” MX000170 all
Quick Disconnect, Socket, 1/8” MX000169 all
Reservoir, 4 Qt MX000161 all
Valve Coil, Directional, 24VDC MX000184 all
Valve Coil, Quick Stop, 24VDC MX000185 all except 50VF (X2/X3)
Valve, 2 Position Directional MX000172 all
Valve, Braking MX000657 all except 10 (SS, DS, CF)
Valve, Check, Endhead Main MX000171 all
Valve, Quick Stop MX000173 all
Valve, Relief, 1500 PSI MX000658 all except 50VF (X2/X3)
Valve, Relief, 3000 PSI MX000174 50VF (X2/X3)
Pump pack parts usage equivalent models:
10 applies to 10-C (222 CF), 10-M (333 MS), 10-CM (333 CF)
40 applies to 40-C (222 CE), 40-M (333 E), 40-CM (333 CE)
10 UPS applies to 10-C UPS (222 CDS), 10-M UPS (333 DS), 10-CM UPS (333 CDS)
40 UPS applies to 40-C UPS (222 DCE), 40-M UPS (333 DE), 40-CM UPS (333 DCE)
Call for 50Hz motors, 575VAC 2.0 HP motor, and pump packs.
