Maintenance Schedule
SlideDriver Operator Maintenance Schedule
Name of part
What to do Check at these recommended monthly intervals
1 3 6 12 60
Gate and Hardware Check for damage and wear *1 X
Drive wheels Check for tightness and wear *2 X
Wheel clamp spring Check for clamping tension *3 X
Limit Switches Check for adjustment *4 X
Anchor bolts Check for tightness X
Fluid level Check for loss of fluid *5 X
Hydraulic fluid Drain and replace fluid X
Clock Battery Replace *6 X
Motor Brushes (DC Only) Replace *7 X
Special Notes:
*1 Your gate and its hardware will require more maintenance than the HySecurity operator that is moving the
gate. A damaged gate or worn hardware may cause operation to appear slow or erratic and will result in excess
drive wheel wear. Lubricate the gate hardware more frequently and check for smooth operation by opening the
toggle clamping mechanism and then pushing the gate manually. One person should easily be able to push all
but the largest of gates. Damaged or warped gate panels should be straightened or replaced.
*2 Normally, the drive wheels will last for many years because they are designed to not slip on the rail. The life
of the wheels may be greatly shortened by any of these faults: clamping spring not correctly adjusted, operator
misaligned in relation to gate panel, badly warped gate panel, extremely stiff hardware, and/or loose wheel
mounting bolts (tighten to 35 ft*lb).
*3 Verify that the red clamping spring is compressed tightly so that the drive wheels apply a strong grip on the
power rail. The red spring should normally be compressed to 2” in height.
*4 The limit switch rollers should ride ¼” to ½” below the drive rail, near the center of the channel.
Misadjustment may result in false or early tripping or no limit function at the end of travel. Verify that the limit trip
ramps are tightly bolted to the drive rail.
*5 The oil level should remain approximately one inch below the filler hole. See maintenance instructions for oil
filling. Loss of fluid is not normal and indicates a leak that must be located and repaired. Use Uniflow fluid,
part MX000970, if additional fluid is required.
*6 Replace the Smart Touch Controller battery with DL 2025 / DL 2032 or CR 2025 / CR 2032.
*7 DC Operators use DC motors with 4 carbon brushes which wear in normal operation. Worn brushes can
damage the DC motor. Under severe conditions HySecurity recommends that brushes be checked after 2
years or 250,000 cycles
and the replacement interval be adjusted as necessary.
