SlideDriver Quick Start
These instructions are provided as a quick reference guide to the experienced installer that is already familiar with
all safety precautions and the installation of this gate operator. Do not attempt to install from this guide if you are
inexperienced with this product.
1. Mount the operator with at least four mounting bolts. The operator must be square and spaced 1¾” away
from the gate.
2. Attach the drive rail to every vertical member of the gate at a height 9 1/4“ above the base of the operator.
Use ¼” roll pins to splice multiple sections of rail.
3. Mount the limit switch trip ramps to the underside of the drive rail at each end. Drill 3/8” holes in a position
that will allow the limit switches to be tripped 6-8” before full travel.
4. Connect the electrical power and grounding wire to the loose wires from the On/Off switch at the left corner
of the control box. Be certain the labeled voltage and phase of the operator matches the available supply.
5. Operators are shipped configured for “right hand” operation. (From the secure side, the gate moves to
right on opening). To change the handing, reconnect the hydraulic hoses at the pump in reverse order.
There is a label near the hose connection point describing this procedure. Connecting the hose from the
top motor to the left disconnect results in “left hand” operation
6. With neither limit switch tripped, engage the release mechanism to clamp the wheels to the drive rail and
verify that the red spring is compressed to 2” in height.
7. Turn on the power switch. The Smart Touch LCD display should show, after a 2 second delay, the
characters [uC_0]. This is a setting for the UL user class that must be made before any gate function will
be possible. Press the Select button, then the Next button and change the 0 to be class 1-4 as
appropriate for the site. Press the Select button again to lock the setting.
8. Press the Next button to go to the setting for the gate hand. The LCD display should now show [Sh_0].
The 0 must be replaced by an [Sh L] or [Sh r] before any gate function will be possible.
9. Press the Menu button and the display will jump to the close timer setting [Ct_0]. If a close timer function
is needed, set in the same manner as above. Press the Menu button again to exit to the Run Mode. The
LCD display should now read StoP, but may read oPEn or CloS if any limit switch is tripped.
10. Test the normal operation of the gate. If the hoses are connected incorrectly, the gate will move the wrong
direction. (see step 5). If the gate moves the correct direction, but triggers an Err1 alert, the handing is set
wrong. (see step 8).
11. After normal function has been verified, connect any required accessory device wiring. Note that the
control inputs (Except Fire Department Open and Emergency Close) are all one wire only to the main
terminal strip while the other wire connects to the Common Buss on the nearby power supply board.
12. To access the User menu in the Smart Touch Controller, press the Menu button while there is no active
Open or Close input. The display will scroll system values and stop at the [Ct__] close timer setting.
There are 11 menu items in the User Menu. To reach the more detailed Installer menu, the system must
be in the User Menu first, then simultaneously press Open and Reset. The display will go to [uC__] which
is the first of 34 items in the Installer Menu. Read the instructions before attempting any adjustments!
