Installation and Maintenance Manual
24
D0119, Rev. F
User Menu Functions
User 1 [Ct _]
Close timer setting: This menu item is the automatic close timer for the gate. The factory setting is zero,
which is off. It may be configured up to 99 seconds.
User 2 [hC 0] Momentary Close: This menu item is to configure the system for constant hold push button Close
function. The factory setting is zero, which is momentary contact input.
User 3 [ho 0] Momentary Open: This menu item is to configure the system for constant hold push button Open
function. The factory setting is zero, which is momentary contact input.
User 4 [AP 0]
Power loss function: This menu item only appears if the operator is a DC battery powered version. This
item is to configure what gate function will occur when the AC power fails. See page 56 for more detailed information on
DC operators.
User 5 [ro 0] Radio control option: This menu item is to configure whether a radio input can open only (default) or if
set to 1, also have the ability to close the gate when it is fully open.
User 6 [bF 2] Warn before operate: This menu item controls the warn before operate buzzer and can be configured
three ways. Setting the menu item to zero turns the buzzer off, but we strongly advise leaving this valuable warning
feature active to alert prior to gate motion. Never cut the wires to the buzzer or unplug it. Set to 1 and the buzzer will
sound three seconds before motion and the entire time during gate motion. Set to 2 (default) and the buzzer will sound
three seconds before motion and for the first two seconds of motion.
User 7 [FA 0] Forced open Alert and automatic gate reposition: This function is intended for highly secure facilities.
If it is enabled, by setting the selection to 1, it will reinitiate a closure if a gate is somehow forced to open far enough that
the close limit switch releases. The Alert buzzer will sound immediately, even if it had been turned off, and the motor will
restart to secure the gate fully closed. If the gate is not fully closed within four seconds the motor turns off and the alert
buzzer sounds an intruder alert for thirty seconds. The LCD display reads ALE1.
User 8 [dA 0] Drift Closed Alert and automatic gate reposition: If it is enabled, by setting the selection to 1, it will
restore a gate to back its fully open position if it drifts closed for any reason. The buzzer will sound a warn before operate
alert, even if it had been turned off, and the motor will restart to reopen the gate. The motor will run for a maximum of four
seconds and if the gate is not fully open in this period, the buzzer sounds for ten seconds and the LCD display reads ALE2.
User 9
[PE 0] PE Alignment Mode: This feature may be activated as an aide to photo-eye emitter / receiver alignment.
The buzzer chirps once as the photo eye is triggered or twice when the photo eye is released. The Alignment Mode is
cancelled with any close limit input or reset input.
User 10 [CL 0] Clock and date set: The Smart Touch Controller is equipped with a 24 hour 365 day clock, so that
events of significance can be logged and stamped with the time and date. This feature is useful to record historical
operation data, which can be accessed via the RS232 port. To set or adjust the hour, minute, day or month, see page 29.
User 11 [Ld 5] LCD Contrast set: Under some extreme high or low temperature conditions, it may be necessary to
adjust the contrast of the LCD display. The display is adjustable from 0-9 with a factory default setting of 5.
User 12
[dD 0] Extended Data Log: When set to 1, the ST Controller logs nearly all Smart Touch Controller events, in
addition to the normal alert, fault and error logs. This parameter automatically resets to 0 after 24 hours – (Requires New
Generation Smart Touch board and version 4.xx software)
