Installation and Maintenance Manual
25
D0119, Rev. F
Installer Menu Functions
Installer 1 [uC 0] Set UL Usage Class: This menu item is used to set the UL usage class, which must be set by
the installer before the operator will function. See page 18, step 3.
Installer 2
[Sh 0] Set Handing of gate: This menu item is used to set the gate handing, which must be set by the
installer before the operator will function. See page 18, step 4.
Installer 3
[Fd 0] Load Factory Defaults: This menu item is used to globally restore all menu settings back to
new machine status. To activate, change the setting from 0 to 1 and push the Menu button. The UL usage class, the
hand configuration and the buzzer type will need to be set again.
Installer 3a
[bu 0] Select Buzzer Type: This menu item selects the type of audible buzzer installed on the
machine. To set, push SELECT on the keypad, the display will flash 0, push OPEN and note the buzzer volume.
Push OPEN again and note the buzzer volume. If this tone is louder, push SELECT, if the first tone was louder, push
CLOSE for the louder tone, then push SELECT to lock in the louder tone.
Installer 4
[dg 0] Set Solo, Master or Slave type: This menu item is used to configure an operator as a Master
or a Slave operator in Master/Slave paired gate installations.
Installer 5
[Ch 0] Set AC Charger or Solar: This menu item appears on 24 VDC battery machines only and is
set to solar only when there is no AC battery charger.
Installer 6
[Fo 0] Enable Fire Dept. Open: This menu item is used to enable the Fire Department Open input.
When set to [Fo_1] this input will override vehicle detectors, photo eyes and gate edges to open a gate. A reset (or
two open commands) is required before the gate can be closed.
Installer 7
[oC 0] Enable Emergency Close: This menu item is used to enable the Emergency Close input.
When set to [oC_1] this input will override vehicle detectors, photo eyes and gate edges to close a gate. A reset is
required before the gate can be opened.
Installer 8
[SE 3] Inherent Sensor sensitivity:. This menu item is to adjust the sensitivity of the internal inherent
sensor. Available settings are 1-9, with 9 being the least sensitive.
Installer 9
[SS 0] Inherent Sensor function: This menu item is only available in UL class 4 operators and allows
an option whereby the inherent sensor will only stop the gate.
Installer 10
[LC 0] Leaf delay Close: This menu item only appears if the operator is set up as a Master or a
Slave. Available settings are 1-7. Each increment adds ½ second, to a maximum of
3 ½ seconds time delay, before the operator activates when commanded to close.
Installer 11
[Lo 0] Leaf delay Open: This menu item only appears if the operator is set up as a Master or a Slave.
Available settings are 1-7. Each increment adds ½ second, to a maximum of 3 ½ seconds time delay, before the
operator activates when commanded to open.
Installer 12
[rt 0] Maximum run timer: The maximum run timer has a default setting of 60 seconds. This menu
item allows an optional setting of 300 seconds, if changed to [rt_1].
Installer 13
[Po 0] Partial Open distance: This menu item both activates the partial open input and allows an
adjustable distance by setting the open duration. The available time settings are 7-99 seconds. The default setting
of [Po_0] leaves this input inactive.
Installer 14
[EC 0] PEC (photo eye close) reverse to open: The default for this menu item is for non-reversal if
the close photo eye is triggered. The optional setting of [EC_1] will cause the gate to reverse to open for two
seconds if triggered while closing.
