Installation and Maintenance Manual
2
D0119, Rev. F
Descriptions for Various Models Derived from SlideDriver 10
For Heavy Gates: SlideDriver 40 222 E Models (UL class I, II, III, and IV)
This model uses a hydraulic manifold with two adjustable brake valves. The brake valves extend the maximum
gate weight capacity from 1,000 pounds to up to 4,000 pounds. Brake valves are highly recommended for heavy-
duty applications.
High Speed: SlideDriver 30F 222 EX 1.7 Models (UL class III and IV only)
The AWOG Soft Starting system and brake valves are keys to safely moving gates faster than one foot per
second. These devices, together with our hydraulic drive, create smooth and predictable handling for both small,
lightweight to 3,000 lb. gates. The SlideDriver 30F, 30F-C, and 30F UPS models use a higher flow rate pump to
achieve a speed of 20 inches per second.
High Speed, Very Heavy: SlideDriver 50VF2, 50VF3
222 X2, X3 Model (UL class III and IV only)
SlideDriver 50VF operators use a variable frequency drive, larger wheels and a higher flow rate pump to reach
36” per second. These operators are designed for very heavy, up to 5,000 lb. gates moving at very high speed.
The Variable Frequency Drive moves very heavy gates at speeds to up to 36 inches per second (50VF3).
SlideDriver 50VF models close gates to a very precise point and are extremely easy on gate hardware. These
operators use the same powerful Smart Touch controller and simple, reliable HySecurity hydraulics as all
SlideDriver models. Note: SlideDriver 50VF models use Installation and Reference Manual D0125.
For Heaviest Gate: SlideDriver 200 (444 XS)
The 444 type operators are for the heaviest gates, weighing up to 20,000 lbs. They employ a much larger chassis
with four drive wheels and hydraulic motors, and a five horsepower electric motor to generate up to 1200 pounds
of draw bar pull.
SlideDriver, DC 24-Volt UPS (Uninterruptible Power Supply) (UPS)
These gate operators function from 24 Volts DC Batteries all of the time to achieve a true UPS system. Our
Uninterruptible Power Supply
is the most certain way to know that your gate will work when the local AC power
fails. This system features fully sealed maintenance free batteries in a separate insulated and ventilated
enclosure and provides at least 3,000 feet of backup gate travel.
SlideDriver C, Correctional Facility (-C)
The CF models offer an extra heavy 10-gauge cover with three different locking options. Type C operators are
shipped ready to interface to the many options and interlocks commonly used at correctional facilities, such as
gate position outputs, interlock capability for sally ports and an interface relay to control an external solenoid lock.
SlideDriver M, Modular
(-M)
This family of operators is a two part modular version of the standard SlideDriver operator. The motor, hydraulic
pump and electric controls are located in a separate enclosure, often at a distance from the drive unit. This
version allows for a more flexible placement of the operator, which may be required or desirable in some
situations involving unique mounting, special security including blast mitigation, or those requiring a very quiet
operator.
SlideDriver S, Solar (-S)
Most SlideDriver operators are available in a DC drive, solar powered version. Call 1-800-321-9947 or visit our
website at www.hysecurity.com for more information.
The Smart Touch Controller
This is the brain of HySecurity’s automatic operators. Groundbreaking technology built sturdy to reliably serve in
the harshest environments. The Smart Touch Controller can quickly be configured by an installer or user to adapt
to nearly any functional requirement for a specific site and comes standard on all HySecurity gate operators. All
system settings are performed with the use of just four programming buttons and an LCD display. The Smart
Touch Controller has no switches to set. An RS232 port for external communication is standard. A real time clock
and an EEPROM record system events. A log of events can be downloaded from the RS232 port to a laptop
computer to evaluate abnormal gate system operation. HySecurity HY-5A vehicle detectors set a new industry
standard by communicating valuable performance data to the Smart Touch controller, allowing quick and in-
depth, user-friendly diagnostics.
