Correctional Facility – User Optional Wiring
A special terminal strip has been pre-wired to the three user relay outputs in Correctional Facility (CF) models
for easy field wiring of the common interconnect options. If alternate output functions are required, see page 28,
Options for User Programmable Output Relays 1-3. NOTE: User 3 Relay on New Generation Smart Touch
boards (after Sept. 2006) is rated for DC only up to 48V and does not have an N.C. (normally closed)
connection.
Connecting an Interlocked Pair:
An interlocked pair of operators is not a Master/Slave system. It is two gate operators interlocked such that the one
cannot open unless the other is fully closed. This connection is used frequently at correctional facilities for Sally Port
gates. The Smart Touch Controller provides both the required interlock input (#7) and the interlock output contact.
1. User relay 3 on the Smart Touch Board has been set by the factory to provide the necessary interlock function.
Connect a total of four wires between operator #1 and operator #2 as follows: One wire to the Common buss
of each operator to the User 3 relay COM terminal of the other operator. Then, connect wires from the User 3
relay NO terminal to the Interlock input (#7) of the other operator.
2. If User relay 3 has already been used for a different function, then one of the other relays User 1 or User 2
must be wired as described above and set to output function 1. The user relays are configured in the Installer
Menu as item [r1__], [r2__] or [r3__] according to the definitions described on page 28-29.
3. The interlock input, terminal #7, is convertible to alternately be a time clock input, so it is possible that it
may need to be switched back for the interlock function. If this alteration is needed, go to the Installer
Menu, and set item [tC _] to be [tC_1].
Connecting to an External Lock Mechanism:
The Smart Touch Controller can command an external solenoid lock or maglock to unlock just before gate motion
begins.
1. User relay 2 has been set by the factory to provide the necessary output for a solenoid lock. Connect
the voltage matching the lock solenoid to User 2 COM and connect a solenoid coil to User 2 NO
(connect a maglock coil to User 2 NC). The un-switched solenoid or maglock wire connects directly to its
supply voltage common conductor.
2. If User relay 2 has already been used for a different function, then one of the other relays User 1 or User
3 must be wired as described above and set to output function 6. The user relays are configured in the
Installer Menu as item [r1__], [r2__] or [r3__] according to the definitions described on page 28-29.
Connecting the Gate Secure Position Indicator Output:
The Smart Touch controller can signal an external device that the gate is secure.
1. User relay 1 has been set by the factory to provide the necessary output for position indication. Connect
the voltage matching the indicator light to User 1 COM and connect the gate secure light to User 1 NC.
The other indicator light wire connects directly to the voltage common conductor. If an unsecured light is
required, connect it to User 1 NO.
2. If User relay 1 has already been used for a different function, then one of the other relays, User 2 or
User 3, must be wired as described above and set to output function 1. The user relays are configured
in the Installer Menu as item [r1__], [r2__] or [r3__] according to the definitions described on page 288-
29.
