Installer Menu Functions
continued
Installer 15 [EO 0] PEO (photo eye open) reverse to close: The default for this menu item is for non-reversal if
the open photo eye is triggered. The optional setting of [EO_1] will cause the gate to reverse to close for two
seconds if triggered while opening.
Installer 16 [gr 0] Edge reverse to open: Default for this menu item is a 2 second reversal if the gate edge is
triggered. The optional setting of [gr_1] causes the gate to reopen fully if triggered while closing.
Installer 17 [Sr 1] IES (inherent sensor) reverse to open: The default for this menu item is for a 2 second
reversal if the inherent sensor is triggered. The optional setting of [Sr 0] will cause the gate to reopen fully if triggered
while closing.
Installer 18 [PC 0] Set PEO/ PEC – NO/NC: The default for this menu item is for photo eyes with Normally Open
outputs. The optional setting of [PC_1] will require a Normally Closed output. If set for NC the connection is also
supervised and any open or short circuit fault will generate a FAL2 alert, which requires a Stop button reset to re-
enable any function if triggered.
Installer 19 [gC 0] Set Edge input – NO/NC: The default for this menu item is for edge sensor with Normally
Open outputs. The optional setting of [gC_1] will require a N.C. output.
Installer 20 [tC 1] Time clock / Interlock input: This menu item configures the input at terminal #7 to be either
for the gate interlock function, as described on page 27, or for an external time clock to open input, as described on
page 44. The default setting is [tC_1] for the interlock function.
Installer 20a [dt 0] Disable Free Exit / Close timer: This input configures the input at terminal #9 to disable either
the Free Exit Detector on terminal #8, or the Timer To Close function. Default setting is [dt 0] allowing disabling of
the free exit detector. NOTE: The free exit is disabled using this menu item when the operator is sitting on its closed
limit. If the closed limit is not tripped, the free exit continues to work.
Installer 21 [or 1] OOLD (Outside Obstruction Loop Detector) function: The default for this menu item is for full
reversal when the OOLD is triggered. The optional setting [or_0] causes the gate to only pause when triggered.
Closure begins as soon as the loop is clear again.
Installer 22 [ir 1] IOLD (Inside Obstruction Loop Detector) function: The default for this menu item is for full
reversal when the IOLD is triggered. The optional setting [ir_0] causes the gate to only pause when triggered.
Closure begins as soon as the loop is clear again.
Installer 23 [dL 1] Vehicle detector logic: This menu item is used to configure quick close and anti-tailgate logic.
There are four modes. See the full description on page 43.
Installer 24, 25, 26 [r1 0], [r2 0], [r3 0] User output relay 1 - 3 options: These three menu items are used to
configure the function of the three user output relays. There are 21 optional choices, which are described in detail on
page 28 - 29.
Installer 27 [t L 0] Gate Open alert: This menu item is to adjust the time delay before activating the user relay
function #8, described on page 28. Time settings up to 135 seconds.
Installer 28 [Lt 0] Loitering alert: This menu item is to adjust the time delay before activating the user relay
function #13, described on page 28. Time settings up to 135 seconds.
Installer 28a [SA 0] System Address: Set the system address for network communication. 0 = no network
communication, 1-99 set individual poling addresses. Requires v4.24 software or higher.
Installer 29 [ELd0] Factory ELD: Controls the HY-5A Free Exit detector, see page 42.
Installer 30 [iLd0] Factory IOLD: Controls the HY-5A IOLD detector, see page 42.
Installer 31 [oLd0] Factory OOLD: Controls the HY-5A OOLD detector, see page 42.
Installer 32 [SLd]. Factory SLD: Controls the HY-5A Shadow detector, see page 42.
