68
Chapter 9: Printer Specifications
Physical Specifications
Characteristic 2” Ci or Cxi Printer 4” Ci or Cxi Printer
Height 7.1” (181mm) 7.1” (181mm)
Width 5” (127mm) 6.9” (175mm)
Depth 10.04” (255mm) 10.04” (255mm)
DT Weight 5.02 lbs (Cxi) 4.91 lbs (Ci) 5.91 lbs (Cxi) 5.88 lbs (Ci)
TT Weight 5.23 lbs (Cxi) 5.00 lbs (Ci) 6.10 lbs (Cxi) 6.00 lbs (Ci)
Software
C Series Administrator: Printer with USB/Serial bi-directional configuration software,
included with printer requires Windows driver installation.
C Clean Driver Utility: Self contained driver cleanup utility that entirely removes old
drivers.
Windows™ OS Drivers: Printer drivers that allow applications running on Windows
operating systems to print to CognitiveTPG printers.
Preventive Maintenance
CognitiveTPG recommends cleaning the printer on a regular basis using standard
CognitiveTPG printer parts and cleaning supplies.
Cleaning
The exterior is cleaned with a lint-free cloth, and if necessary, a mild detergent solution
in a damp cloth. It is recommended that interior components are cleaned with the
authorized cleaning supplies listed below every 20,000 inches (508 m) or blown air to
remove any particles. The printhead should be cleaned every 5000 inches if preprinted
labels are used. The platen should be cleaned at the same interval, using the same
cleaning materials as applied to the printhead. Please refer to Chapter 11 for more
details on cleaning supplies.
Warranty
Printer: 24 months from date of purchase. (requires registration and excludes
printheads)
Printhead: 6 months or 500,000 inches using CognitiveTPG’s approved media
MTBF (Mean time between failures): 2,000,000 inches (Does not include printhead
dots out condition)
