Chapter 2: Getting Started
Inside the Printer
Figure 2-2. C Series Side View
Device Use
A – Large roll spindle slot Holds large roll media
B – Standard roll spindle slot Holds standard roll media
C – Cast metal user interface cover Contains user interface buttons
D – Printhead Printing mechanism
E – Printhead bracket Holds the printhead
F – Ribbon drive gears Feeds ribbon through the printer
Paper Media Guide Bar
Figure 2-3. C Series Inner Side View of Media Bar
A
B
C
D
E
F
A
