8
Chapter 2: Getting Started
Understanding the LCD Menu Structure
MAIN MENU
USER MENU
LCD Contrast Contrast 0 … 8
Backlight Control ON or OFF
Language Menu English, Spanish, French, Russian
Beeper Volume Volume 0 … 3
Set Date and Time Date (MM/DD/YY) Time (HH:MM:SS)
SETUP MENU
COMM Menu
Serial BAUD 1200, 2400, 4800, 9600, 19200, 38400,
57600, 115200
PARITY Even, Odd, None
DATA Bits 7 or 8
STOP Bits 1 or 2
Ethernet DHCP ON or OFF
Set Static IP XXX.XXX.XXX.XXX
Set Subnet XXX.XXX.XXX.XXX
Set Gateway XXX.XXX.XXX.XXX
Transfer Mode Direct Thermal or Thermal Transfer
Speed High, Normal, Low
DPI Select 200dpi Selectable 200 or 100 dpi
300dpi Selectable 300 or 150 dpi
Index Bar, Gap, Notch
Width 16 … 425 Quick UP / DWN key press increments by 1; Press and
hold increments by 10
Top Of Form Adjust 0 … 2000 Quick UP / DWN key press increments by 1; Press and
hold increments by 10
Darkness -200 … 813 Quick UP / DWN key press increments by 1; Press and
hold increments by 10
Feedback ON or OFF
Report Level 0 = None, 1 = Serial, 2 = Label
Timeout 0 … 65535 Quick UP / DWN key press increments by 1; Press and
hold increments by 10
Shift Left -Printhead...
+Printhead
Quick UP / DWN key press increments by 1; Press and
hold increments by 10
Present Label ON or OFF
Advance 0 ... 2000 Quick UP / DWN key press increments
by 1; Press and hold increments by 10
Retract 0 ... 2000 Quick UP / DWN key press increments
by 1; Press and hold increments by 10
Time 0 ... 100 Quick UP / DWN key press increments
by 1; Press and hold increments by 10
CALIBRATION MENU
Calibration Menu Start? Based on Bar, Gap or Notch index setting
TEST MENU Label or Objects
OPTIONS MENU External 5 volts ON or OFF
SETTINGS MENU
Save Settings Yes? Or No?
Read Settings Yes? Or No?
Factory Defaults Yes? Or No?
CUSTOMER
SUPPORT
Phone: 1-800-525-2785 Web: www.CognitiveTPG.com
RETURN Return to Main Menu
