Rev. 8/02 -4. 14- TFXM
logger module and the uploading of the file data can take up to
several minutes. The files will appear on the table, See Figure
4.12, in a list running from the earliest file to the latest file.
Information regarding starting time and date and points collected
will appear.
If a file is selected, the time stamped data will appear on the strip
chart located on the bottom of the window. The mouse can be
used to select a small portion of the graph and expand the data to
the width of the screen. To revert to the entire data file, right-click
the graph.
To save the file to a file on your computer, select the file from the
file table and press the Save button located on the top task bar.
See Figure 4.13. Datalog saves the files as a .CSV (Comma
Separated Value). These files can be opened in programs such
as Microsoft Excel® or Borland QuattroPro® for manipulation or
graphical purposes.
SOFTWARE UTILITIES
Figure 4.13
Save Data Logger Files
Note: The spreadsheet programs listed above are limited to the
number of lines of data that can be imported. Very large files may
need to be opened in a program like Microsoft WordPad and
saved in two or more sections.
