Rev. 8/02
-3. 9- TFXM
Other
This list is provided as an example. Additional materials are
being added continuously. Select the appropriate material from
the list or select OTHER if the liner material is not listed.
LINER SS -- Speed of Sound in the Liner
ENGLSH (Feet per Second)
METRIC (Meters per Second)
Allows adjustments to be made to the speed of sound in the
liner. If the UNITS value was set to ENGLSH, the entry is in
FPS (feet per second). METRIC entries are made in MPS
(meters per second).
If a liner was chosen from the LINER MAT list, a nominal value
for speed of sound in that media will be automatically loaded.
If the actual sound speed rate is known for the pipe liner and
that value varies from the automatically loaded value, the value
can be revised.
FL TYPE - Fluid/Media Type
WATER
SEA WATE
KEROSENE
GASOLINE
FUEL OIL
CRUDE OI
PROPANE
BUTANE
OTHER
This list is provided as an example. Additional liquids are being
added continuously. Select the appropriate liquid from the list
or select OTHER if the liquid is not listed.
PART 3 - KEYPAD CONFIGURATION
Fluid Type
Liner Sound
Speed
