PART 3 - KEYPAD CONFIGURATION
V -- Mount. A reflective type (transducers mounted on one
side of the pipe) of installation used primarily on pipe sizes in
the 3-10 inch [75-200 mm] internal diameter range.
W -- Mount. A reflective type (transducers mounted on one
side of the pipe) of installation used primarily on pipe sizes in
the 1-6 inch [25-75 mm] internal diameter range.
Z -- Mount. A direct type (transducers mounted on opposite
sides of the pipe) of installation used primarily on pipe sizes in
the 10-100 inch [200-2540 mm] internal diameter range.
PIPE OD -- Pipe Outside Diameter Entry
ENGLSH (Inches)
METRIC (Millimeters)
Enter the pipe outside diameter in inches if ENGLSH was
selected as UNITS; in millimeters if METRIC was selected.
PIPE WT -- Pipe Wall Thickness Entry
ENGLSH (Inches)
METRIC (Millimeters)
Enter the pipe wall thickness in inches if ENGLSH was
selected as UNITS; in millimeters if METRIC was selected.
IMPORTANT NOTE: Charts listing popular pipe sizes have
been included in the Appendix of this manual. Correct entries
for pipe O.D. and pipe wall thickness are critical to obtaining
accurate flow measurement readings.
Pipe Wall
Thickness
Pipe Diameter
IMPORTANT NOTE: Charts listing popular pipe sizes have
been included in the Appendix of this manual. Correct entries
for pipe O.D. and pipe wall thickness are critical to obtaining
accurate flow measurement readings.
