Dynasonics TFXM Series Ultrasonic Multi-Channel Flow Meter - Manual (Page 23)

Rev. 8/02
- 2.8 - TFXM
1. The UP/DOWN ARROW keys are used to scroll through
menus and configuration parameters. The ARROW keys
can also be used to adjust parameter numerical values. In
RUN mode the UP/DOWN ARROW keys are used to adjust
the display contrast level.
2. The Numerical Keypad is used for entering numerical
values.
3. The (soft)ACCEPT key is used to
?? accept configuration parameter changes.
5. The (soft)CHAN key is used to
?? Configure the engineering units on the graphics display—
Press the (soft)SELECT key from RUN mode to highlight the
engineering unit presently being displayed on the graphics
display (pressing the SELECT key multiple times will toggle
the highlighted unit from line to line). Use the UP/DOWN
ARROW keys to select display units of
?? RATE
?? TOTALizer
?? VELocity
?? SIGNAL STRength
?? Sound Speed
?? TEMP1
?? TEMP2
?? TEMP Diff
6. When the (soft)MENU key is pressed, the user is prompted
for the measurement channel that is to be configured. Use
the UP/DOWN arrow keys to display the measurement
channel that requires configuration. Press (soft)ACCEPT
when the required channel is visible in the center of the
display.
PART 2 - TRANSDUCER POSITIONING
