Dynasonics TFXM Series Ultrasonic Multi-Channel Flow Meter - Manual (Page 27)

Rev. 8/02
- 2.12 - TFXM
[If a LINER Thickness was selected]
LINER MAT - Liner Material
TAR EPOXY
RUBBER
MORTAR
POLYPROPYLENE
POLYSTYROL
POLYSTYRENE
POLYESTER
POLYETHYLENE
EBONITE
TEFLON
Other
This list is provided as an example. Additional materials are be-
ing added continuously. Select the appropriate material from
the list or select OTHER if the liner material is not listed.
LINER SS -- Speed of Sound in the Liner
ENGLSH (Feet per Second)
METRIC (Meters per Second)
Allows adjustments to be made to the speed of sound in the
liner. If the UNITS value was set to ENGLSH, the entry is in
FPS (feet per second). METRIC entries are made in MPS
(meters per second).
If a liner was chosen from the LINER MAT list, a nominal value
for speed of sound in that media will be automatically loaded. If
the actual sound speed rate is known for the pipe liner and that
value varies from the automatically loaded value, the value can
be revised.
FL TYPE - Fluid/Media Type
TAP WATER
SEWAGE
SEA WATE
KEROSENE
GASOLINE
FUEL OIL
CRUDE OI
PROPANE
PART 2 - TRANSDUCER POSITIONING
Fluid Type Entry
Liner Material
Entry
Liner Sound
Speed Entry
