Appendix Q – ILPC Programming Examples
Class Series Programmer’s Manual
261
ILPC-CHINESE Option
The Chinese Option is a double byte scalable font supporting Simplified GB Chinese. In the double byte
format the printer recalls one character printed from every two 8-bit bytes sent from the host. Double byte
scalable fonts are selected using a print format record (see Generating Label Formats and Appendix H for
details).
DPL Big 5 Encoding Support: With the ILPC Chinese option, the printer firmware supports font files
that are encoded for the GB Character Map and the Big 5 Character Map. The resident Asian font in the
printer is encoded in the GB Character Map. To utilize the Big 5 Character Map, the user must download
a font file that is Big 5 encoded. The font file downloaded must be of a size compatible with the internal
module size available or of a size compatible with an external (plug in) module where applicable. Printing
characters from the Big 5 encoded font file is accomplished by:
1. Setting the character mapping with a System Command or Label Format Command (
yUB5
, respectively).
2. Setting the ‘b’ field = ‘9’ and ‘eee’ field = ‘Unn’, where ‘nn’ is equal to the Font ID number selected
for the Big 5 encoded font file downloaded.
3. Selecting string data corresponding to the Big 5 Character Map.
Scalable Double-Byte Font Map - CHINESE
eee
(Font Code)
Scalable
Font Type
Font
Name
Binary
Addressing
Hex ASCII
Addressing
Code
Pages
UC0
Scalable Resident
Simplified
GB Chinese
√
GB
uc0
Scalable Resident
Simplified
GB Chinese
√
GB
U50 -
U5z...
U90 - U9z
Scalable Non-Resident (download) Big 5
√
B5
u50 - u5z…
u90 - u9z
Scalable Non-Resident (download) Big 5
√
B5
U50 -
U5z...
U90 - U9z
Scalable Non-Resident (download) User defined
√
–
u50 - u5z…
u90 - u9z
Scalable Non-Resident (download) User defined
√
–
Sample Simplified GB Chinese DPL file (binary addressing) and resulting label:
<02>L
D11
ySPM
1911S0003100010P020P015Scalable Chinese Available in GB Character Set
1B110000020017001234567890
yUGB
1X1100001900010b0392011000020002
112200002800030GB CHARACTER’S IN ALL 4 ROTATION’S
112200002600030Rotation 1
1911UC002650150P012P012
112200002400030Rotation 2
