Appendix K – Print Resolutions, Module Identifiers, Maximum Field, Column, & Character Values
Class Series Programmer’s Manual
242
Printer
Module
ID
Description
A-
Class
E-Cla
ss
EX2
[10]
I-Cl
ass
M -Cl
ass
(N
D)
M-Class
W-Cl
ass
H-Class
S-Cl
ass
A
DRAM (512 KB - default size)
X
X
X
X
Flash (256 KB available to user)
X
X
X
B
[1]
Flash (512 KB available to user)
X
C
Default, as assigned by
X X X
X X X X X
X
DRAM (512 KB - default size), configurable.
X
X
D
DRAM (default 1MB), configurable.
X
X
X
X
X
SDIO
X
F
4 MB Flash – Option, configurable.
[6]
X
X
256 KB Flash, Main CCA
[2, 5]
X
X
X
128 KB Flash, Main CCA, configurable up to 6.25 MB with Flash option
[3, 6]
X
512 KB Flash, Main CCA, configurable up to 6.5 MB with Flash option
[3, 6]
X
G
≈ 5.0 MB Flash, Main CCA
[6, 7]
X
[9]
X
H
USB Host Ports (as equipped)
X
I
USB Host Ports (as equipped)
J
64 MB option (as equipped)
X
ILPC Module, configurable 256 KB to 6.5 MB (as equipped).
X
[3,6]
X
[8]
[4]
X
[3,6]
[4]
X
[7]
64 KB Flash – Menu / EFIGS – protected
X
X
X
Y
128 KB Flash – Menu / EFIGS – protected
X
X
[8]
X
[7]
Z
[6]
4 MB Flash – Option ILPC – protected
X
X
[1]
Dependent upon options and available memory; see the configuration label or
≈
100,000 writes for semi-or-permanent storage of images, fonts and formats.
[2]
Not available for the I-4206 and I-4208.
[3]
Modules G and X are partitioned to equal the sum of the total space available: 6.5MB A-Class; and, 6.25MB M-Class.
[4]
Module X hosted the ILPC template for a short period.
[5]
Decreased due to added features.
[6]
Configurable; see
[7]
Modules X and Y are factory allocated and locked; space is used / removed from Module G.
[8]
Modules X and Y are treated as folders or subdirectories within B, and space is used / removed from Module B.
[9]
Size dependent on main board flash size, and options installed, up to 6.0MB
[10]
Queries report modules A and B, X and Y only.
Table K-5: Memory Module Identifiers and Default Memory Allocations
