Extended System-Level Command Functions
Class Series Programmer’s Manual 87
(ST) Sensor Type – See e (edge) or r (reflective) for command details. (For non-
display models also see the KD command.)
(SV) Switch Settings – This command controls recognition of the software switch setting
command V.
(TB) TOF Bias – This command controls the low-level voltage difference level to recognize a
label ‘gap’ or ‘mark’.
(TD) TOF Delta – This command controls the low-level voltage difference level to recognize a
label ‘gap’ or ‘mark’.
(TG) TOF Gain – This command controls the voltage to the LED emitter of the Media Sensor.
(TN) No Paper Min – This command sets the media sensor level for the Out of Stock (OOS)
condition.
(TP) TOF Precedence – This command instructs the firmware to stop printing at the first top of
form mark it detects. The default, ‘No,’ prints all of the data (traversing the top of form as
necessary) then slews to the next TOF.
(UM) Units of Measure – See m (metric) or n (imperial) for command details.
(UT) User Terminator – This command allows word wrapping of long character strings of
commands to the next line in a file, for the purposes of readability only. In the Kc string,
the command UTON must fall somewhere before the first line terminator. The last command
needs to be END, followed by a line terminator (see the KcEN command for details).
(VE) Verifier Equipped – This command enables the GPIO for a bar code verifier (see Appendix
J). A or Y - automatically senses device presence; if undetected, no error is generated. E - enables
the device, where its presence must be detected; otherwise, a fault is generated. N or D - disables
device detection.
(VT) Verifier Type – This command is reserved for future use.
