Datamax-O'Neil Class Series Programmer’s Manual User Manual
Page 194
Appendix F – Barcode Summary Data
Class Series Programmer’s Manual
180
203 DPI Resolutions
300 DPI Resolutions
400 DPI Resolutions
600 DPI Resolutions
Font
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
U/u
1.00
N/A
1.00
N/A
1.00
N/A
1.00
N/A
v
.5
1
.5
1
.5
2
.5
3
z
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Z/z
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
W1C/W1c
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
W1D/W1d
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
W1F/W1f
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
W1I
.40
2
.40
4
.40
4
.40
6
W1J
.40
2
.40
4
.40
4
.40
6
W1k
N/A
2
N/A
3
N/A
4
N/A
6
W1p
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
W1G/W1g
.5
5:2
.5
7:3
.5
9:4
.5
14:6
W1R
1.40
2
1.40
4
1.40
4
1.40
6
W1T
.40
6:2
.40
9:4
.40
12:4
.40
18:6
W1Z/W1z
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Table F-2: Bar Code Default Data
Note: Some bar codes will be sensitive to Label Command ‘D’ (set dot width and height size); see Label Formatting Commands for details.
