Appendix C – Available Fonts
Class Series Programmer’s Manual
161
Font
Height
Width
Spacing
Point Size
Font 0
20
14
2
2.4
Font 1
38
20
6
4.6
Font 2
54
30
6
6.5
Font 3
80
42
6
9.6
Font 4
106
54
8
12.7
Font 5
154
54
8
18.5
Font 6
190
94
12
22.8
Font 7
94
44
14
11.3
Font 8
82
44
14
9.8
Table C-5: Font Sizes @ 600 DPI Resolution
Internal Smooth Font 9 (Smooth Font) Point Size Specifiers
Label format records with font code 9 (in Format Record header field b) can specify any of the font sizes
in the leftmost column of the table below. The corresponding specification in either column labeled Ann
or 0nn is used in the font size/selection (eee height) field to select the desired font size. Optional font
sets may contain subsets of those described here. For an optional font set that generates these fonts via
scalable font technology, the character mapping for this font is the selected scalable symbol set (see
Appendix E).
In the sample format below, a 300 DPI printer will use 4-point smooth font to produce a printed label
with the words “four point font”. Sample format:
1911A0400100010four point font
E
Smooth Font 9 Font Size Specification Syntax
Ann
Point
Size
203 DPI Print Resolution
[1]
300, 400, & 600 DPI Print Resolutions
[2]
0nn
4 -
A04
-
5 -
A05
000
[3]
6 A06
A06
001
8 A08
A08
002
10 A10
A10
003
12 A12
A12
004
14 A14
A14
005
18 A18
A18
006
24 A24
A24
007
30 A30
A30
008
36 A36
A36
009
48 A48
A48
010
72 -
A72
-
[1]
All fonts greater than A36 are created from multiples of smaller fonts, 2x or 3x, as available.
[2]
All fonts greater than A24 are created from multiples of smaller fonts, 2x or 3x, as available.
[3]
Available at 300 DPI and greater print resolutions only.
Table C-6: Internal Bit-Mapped (Smooth Font) 9 Size Chart
