Appendix G – Barcode Details
Class Series Programmer’s Manual
190
T:
Telepen
Valid Characters: All 128 ASCII characters.
Variable Length
Valid bar widths: The fourth character of the record is the width of the narrow bar in dots. All other
bars are a ratio of the narrow bar (2 times, 3 times, and 4 times the narrow bar width).
The following example prints a Telepen bar code:
D11
1T0000000150100ABCDEF
121100000000100Barcode T
E
Barcode T
u:
UPS MaxiCode, Modes 2&3
The printer supports MaxiCode as defined in the AIM Technical Specification. The following
examples illustrate various label format record message syntaxes for encoding data as MaxiCode. In
the following examples, special formatting is used to denote special ASCII characters as shown:
Symbol
Hexadecimal Value
R
S
1E
G
S
1D
E
O
T
04
Printer message syntax allows for
E
O
T
to be substituted with
or the use of both
E
O
T
and
.
UPS Modes 2 & 3 Explicit
The data stream can force Mode 2 or 3 encoding by placing #2 or #3, respectively, before the data,
as shown in the example below. If this is not specified, the printer chooses the best mode.
1u0000001200120#3[)>
R
S
01
G
S
96123456
G
S
068
G
S
001
G
S
1Z12345675
G
S
UPSN
G
S
12345E
G
S
0
89
G
S
G
S
1/1
G
S
10.1
G
S
Y
G
S
G
S
G
S
UT
R
S
E
O
T
This example will print encoding the MaxiCode symbol in Mode 3.
D11
1u0000001200120#3[)>
R
S
01
G
S
96123456
G
S
0
68
G
S
001
G
S
1Z12345675
G
S
UPSN
G
S
12345E
G
S
0
89
G
S
G
S
1/1
G
S
10.1
G
S
Y
G
S
G
S
G
S
UT
R
S
E
O
T
121100000000100Barcode u
E
