IO_OUTP_CTRL 1-3
The outputs (Output mode, Polarity) are controlled via 3 advanced feature
registers (see
Table 29: Advanced register: Output control on page 82).
The Polarity field determines whether the output is inverted or not. The out-
put mode can be viewed in the table below. The current status of the output
can be queried and set via the PinState.
It is possible to read back the status of an output pin regardless of the output
mode. This allows for example the host computer to determine if the camera
is busy by simply polling the BUSY output.
Note

Outputs in Direct Mode:
For correct functionality the Polarity should always be set
to 0 (SmartView: Trig/IO tab, Invert=No).
Register Name Field Bit Description
0xF1000320 IO_OUTP_CTRL1 Presence_Inq [0] Indicates presence of this
feature (read only)
PWMCapable [1] All Guppy PRO cameras:
Indicates if an output pin
supports the PWM feature.
See Table 31: PWM configura-
tion registers on page 85.
--- [2..6] Reserved
Polarity [7] 0: Signal not inverted
1: Signal inverted
--- [8..10] Reserved
Output mode [11..15] Mode
see Table 30: Output routing
on page 83
--- [16..30] Reserved
PinState [31] RD: Current state of pin
WR: New state of pin
0xF1000324 IO_OUTP_CTRL2 Same as
IO_OUTP_CTRL1
0xF1000328 IO_OUTP_CTRL3 Same as
IO_OUTP_CTRL1
Table 29: Advanced register: Output control
